5.6 Timing

C141-E104-02EN

5-113

5.6.3.3 Sustained Ultra DMA data in burst

5.6.3.2 contains the values for the timings for each of the Ultra DMA Modes.

Note:

DD (15:0) and DSTROBE are shown at both the host and the device
to emphasize that cable setting time as well as cable propagation
delay shall not allow the data signals to be considered stable at the
host until some time after they are driven by the device.

Figure 5.13 Sustained Ultra DMA data in burst

DSTROBE
at device

DD(15:0)
at device

DSTROBE
at host

DD(15:0)
at host

t

2CYC

t

CYC

t

DVS

t

DVH

t

DS

t

DH

t

2CYC

t

CYC

t

DVH

t

DVS

t

DVH

t

DS

t

DH

t

DH
