McQuay Micro Tech Open Protocol Driver Manual Page 39 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
Array Location Read/ Write/ Both Field Name Number of Bytes Base Address Device Scaling Method
4 r Calculated Network Amp Limit Setpoint 1 0x0423 1
5 r Compressor Discharge Temp. 1 0x0407 1
6 r Compressor Suction Temp. - Lo Resolution 1 0x0403 1
7 r Compressor Suction Temp. - Hi Resolution 1 0x041C 7
8 r Condenser Pump 1 0X021C 1
9 r Condenser Refrigerant Pressure 1 0x0411 1
10 r Condenser Refrigerant Temp. 1 0x0408 1
11 r Condenser Water Flow Switch 1 0X050F 1
12 r Cooling Tower Stage 1 1 0x0218 1
13 r Cooling Tower Stage 2 1 0x0219 1
14 r Current Fault 1 0x0428 1
15 r Fault Last 1 0x0834 1
16 r Fault 2 1 0x0835 1
17 r Fault 3 1 0x0836 1
18 r Fault 4 1 0x0837 1
19 r Fault 5 1 0x0838 1
20 r Fault 6 1 0x0839 1
21 r Fault 7 1 0x083A 1
22 r Fault 8 1 0x083B 1
23 r Entering Condenser Water Temp. - Lo Resolution 1 0x0405 1
24 r Entering Condenser Water Temp. - Hi Resolution 1 0x041E 8
25 r Entering Evaporator Water Temp. - Lo Resolution 1 0x0401 1
26 r Entering Evaporator Water Temp. - Hi Resolution 1 0x041A 1
27 r Entering Water Reset 1 0x0438 1
28 r Evaporator Low Pressure Switch 1 0x050E 1
29 r Evaporator Pump 1 0X021B 1
30 r Evaporator Refrigerant Pressure 1 0x0410 1
31 r Evaporator Refrigerant Temp. - Lo Resolution 1 0x0402 1
32 r Evaporator Refrigerant Temp. - Hi Resolution 1 0x041B 7
33 r Evaporator Water Flow Switch 1 0X050F 1
34 r High Discharge Pressure Switch 1 0X050E 1
35 r Hot Gas Solenoid 1 0x0212 1
36 r Leaving Condenser Water Temp. - Lo Resolution 1 0x0406 1
37 r Leaving Condenser Water Temp. - Hi Resolution 1 0x041F 8
38 r Leaving Evaporator Water Temp. - Lo Resolution 1 0x0400 1
39 r Leaving Evaporator Water Temp. - Hi Resolution 1 0x0419 7
40 r LED Front Panel 1 0x021F 1
41 r Lift Pressure 1 0x0412 1
42 r Liquid Injection Solenoid 1 0x0216 1
43 r Liquid Line Refrigerant Temp. - Lo Resolution 1 0x0404 1
44 r Liquid Line Refrigerant Temp. - Hi Resolution 1 0x041D 8
45 r Liquid Subcool 1 0x0417 1
46 r Load Solenoid 1 0x0211 1
47 r Low Evaporator Pressure Limit 1 0x043B 1
48 r Manual Amp Limit 1 0X043D 1
49 r Manual Amp Limit Setpoint 1 0x0901 1
50 r Maximum Amp Limit 1 0X043C 1
51 r Motor Control Latch Relay 1 0x0213 1
52 r Motor Control Relay 1 0x021E 1
54 r Motor Current Amps 2 0x0435 1
55 r Motor Current Percent 1 0x040C 1
56 r Motor Temperature Switch 1 0x050E 1
58 r Number of Starts 2 0X0432 1
