McQuay Micro Tech Open Protocol Driver Manual Page 17 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
6.2 Client Side Node Parameters
Section Title
Nodes
Column Title
Function Legal Values
Node_Name Provide name for Node
Up to 32 alphanumeric
characters
Protocol Specify protocol used MCQ, McQuay
Port Specify which port the device is connected to the FieldServer P1-P8, R1-R22
PLC_Type
The name of the McQuay Equipment type being polled. The
equipment type must be known for the driver to operate
correctly. 200CFC, 100CFC, 050RPC,
001ASC,
000SCU, Type-
Unknown
Password Maximum of 8 characters. Ascii characters only.
Node_Hi
Specify the rotary Hi address switch setting of the Mcquay
controller
0 to F
Node_Lo
Specify the rotary Lo address switch setting of the Mcquay
controller
0 to F
// Client Side Nodes
Nodes
Node_Name , Node_Hi , Node_Lo , Protocol , Port , Password , PLC_Type
Node_200CFC , 3 , B , McQuay , P1 , 85760430 , 200CFC
2 Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
