7.2 Server Side Node Parameters
Section Title
Nodes
Column Title
Function Legal Values
Node_Name Provide name for node Up to 32 alphanumeric characters
Protocol Specify protocol used MCQ, McQuay
Port*
Specify which port the device is connected
to the FieldServer. This parameter is
optional for Server side nodes. The reason
is that when a poll is received on any port
an attempt will be made to match it
against
any Map Descriptor/node
irrespective of the port. If emulating more
than one Node with the same address,
however, the Nodes must be linked to
specific ports.
P1-P8, R1-R2 4
PLC_Type
This parameter has no meaning for a
Server but it must be specified to allow the
driver to complete its configuration file
validation.
200CFC, 100CFC, 050RPC, 001ASC, 000SCU, Type-
Unknown
Password*
This parameter is ignored for a Server.
Although every poll contains a password,
this driver does no password validation
when configured as a Server.
Ascii characters only.
Node_Hi
Specify the rotary Hi address switch
setting of the Mcquay controller
0 to F
Node_Lo
Specify the rotary Lo address switch
setting of the Mcquay controller
0 to F
Example
// Server Side Nodes
Nodes
Node_Name , Node_Hi , Node_Lo , Protocol , PLC_Type , Password
Node_A
, 3 , B , McQuay , 200CFC , 85760430
7.3 Server Side Map Descriptors
7.3.1 FieldServer Specific Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric characters
4 Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
