McQuay Micro Tech Open Protocol Driver Manual Page 32 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
Appendix C. Reference
Appendix C.1. Error Messages
Those messages marked with an * are only printed once even if they occur repeatedly.
Error Message Action
McQuay:#1 FYI. The MapDesc called <%s> is too
short
The length of the Map Descriptor used to expose driver
statistics is too short. Set the length to at least 1000.
You can ignore this message – the driver will abandon
excess statistics.
McQuay:#2 FYI. You could have used a MapDesc
called <%s> to expose diagnostic info. You can safely ignore this message. It is a prompt. Refer
to Appendix C.2.
McQuay:#3 FYI. Normally passwords are defined for
each node.
This is a reminder that a password is expected when a
node is defined. Refer to sections 6.2 or 7.2. Even though
password checking is not enforced when the driver is
configured as a Server, the driver expects one to be
defined for every node.
McQuay:#4 Err. Node list if full. Max=%d
A maximum of 100 McQuay device nodes can be
configured per FieldServer. If the limit is reached, call
support.
McQuay:#5 Err. Node=%d has more than one
password.
A node has been provided with two passwords. This is
either a configuration error or two nodes with the same
address are connected to different ports. The driver can
only store one password per node address and cannot
use the port number to differentiate them. Re-program
the McQuay devices to have the same passwords if they
have the same addresses.
*McQuay:#9 FYI. Device scaling method unknown.
Device Scaling is being applied and the driver doesn’t
know how to scale a variable. Please submit your
configuration file with your request for support.
McQuay:#10 Err. Node=%s. Equip. type not
recognized.
The driver doesn’t recognize the equipment type
specified using the PLC_Type parameter in the
configuration file. Refer to Appendix C.3 for a list of valid
equipment types.
5
McQuay:#11 Err. Node=%s. Equip. Type not
specified.
Refer to Sections 6.2, 7.2. and Appendix C.3
5
McQuay:#13 Err. MapDesc=%s. Field Name
unknown.
Refer to Appendix C.3 for a list of valid field names. Refer
also to Sections 6.3 or 0.
McQuay:#14 Err. MapDesc=%s. Max Len=1 for
Writes with direct addr. Corrective action is required. When writing to a McQuay
device using direct addressing the length may only be 1
5
5 Correct the configuration by editing the CSV file and downloading it to the FieldServer, then reset the FieldServer for the changes to take
effect.
