General Specifications
Installation Checklist
q . Inspect.all.components.and.accessories.for.damage.before.and.after.
installation.
q . Remove.the.cardboard.wall.sleeve.support.and.grill.weatherboard.
q . Check.for.proper.wall.sleeve.installation.in.accordance.with.the.wall.
sleeve.installation.instructions.
q . Check.for.a.subbase.kit.or.other.means.of.structural.support.which.
is.required.for.ALL.installations.projecting.more.than.8".into.room.
q . Install. the. recommended. Condensate. Drain. Kits. for. complete.
condensate.removal.
q . Ensure.that.the.chassis.is.installed.in.a.16".high.x.42”.wide.wall.sleeve.
that.is.no.deeper.than.13.¾"...A.baffle.kit.is.required.if.the.sleeve.
exceeds.that.depth.
q . Ensure.that.chassis.and.chassis.front.cover.are.installed.and.secured.
properly.
q . Ensure.that.drapes,.bed,.bedspread,.furniture,.etc...DO.NOT.block.
either.return.or.discharge.air.grilles.
q . Inspect.the.condenser.air.inlet.and.outlet.for.any.obstructions.
(shrubbery,.etc.)
q . Ensure.that.'reset'.button.is.pressed.on.LCD.device.(only.on.cord.
connected.models).
MODEL NUMBER
07 = 7,000 Btuh
09 = 9,000 Btuh
Nominal Capacity
12 = 12,000 Btuh
15 = 15,000 Btuh
Series
PD = Friedrich Digital PTAC
System
X = Accessory
E = Cooling with or without electric heat
H = Heat Pump with Auxiliary Heat
Voltage
K = 230/208V - 1 Ph. - 60 Hz.
R = 265V - 1 Ph. - 60 Hz.
Nominal Heater Size (230V or 265V)
0 = No Heater*
2 = 2.0 KW 3 = 3.0 KW 5 = 5.0 KW**
*
**
No Heater only available on 230V PDE models
5.0 kw only available on 9000, 12000 and 15000 BTU models
Chassis
S = Standard
Design Series
Note: All PTAC models with a C design series or
later come standard with Diamonblue seacoast
protection and digital controls.
Engineering Digit
PDXWS Wall Sleeve Dimensions:
16" H x 42" W x 13-¾" D
Front Cover Dimensions:
16" H x 42" W x 7-¾" D
Cut-Out Dimensions:
16-¼" x 42-¼"
Typical Unit Components and Dimensions
FILTERS
RETURN AIR GRILLE
FRONT COVER
CHASSIS
OUTDOOR GRILLE
WALL SLEEVE
DISCHARGE
GRILLE
