FUJITSU M3000 User Manual
Page 62

A-6
SPARC Enterprise M3000 Server Installation Guide • January 2009
The switches on the operator panel include the mode switch for setting the operation
mode and the power button for turning on and off the server.
TABLE A-1
LEDs on the Operator Panel
Icon
Name
Color
Description
POWER
LED
Green
Indicates the server power status.
On: The power to the server is on.
Off: The power to the server is off.
XSCF
XSCF
STANDBY
LED
Green
Indicates whether the XSCF is ready.
On: XSCF unit is functioning normally.
Off: XSCF unit is stopped.
Blinking: Under system initialization after the AC
power is turned on, or under server power-on
processing.
CHECK
LED
Amber
Indicates that the server has detected an error.
On: An error that hinders startup was detected
Off: Normal, or the power supply is interrupted
(power failure)
Blinking: Indicates that the unit is a maintenance
target. This is sometimes called a locator
