2-22
ITEM PART # COMPONENT
1 810-2793 Basket Hanger, Wire Form
2 803-0028 Basket Hanger, Extruded Aluminum (replaced by 810-2793)
3 823-1462 Basket Hanger, Burger King
* 106-2186 Basket Hanger Assembly, Burger King (includes Items 1, 4 and 13)
4 106-2185 Bracket, Burger King Easy-Off Basket Hanger (used w/Item 1)
5 809-0171 Thumbscrew, ¼-20 X 1⅜-inch Basket Hanger
* 809-0921 Spacer, Basket Hanger
6 826-1351 Nut, Cage (receives Basket Hanger Thumbscrew) (Pkg. of 10)
7 806-9257SP Roller Assembly, Basket Lift (Complete)
8 910-8284 Bracket, One-Piece Roller Guide
9 826-1334 Capscrew, ¼ – 20 x 1¼” Stainless Steel Hex Head (Pkg. of 5)
10 809-0190 Washer, ¼” Stainless Steel Flat
11 810-0374 Spacer, Tubular
12 810-0194 Roller, Basket Lift Guide
13 809-0047 Nut, ¼ – 20 Cap (also used w/Item 4)
14 Flue Cap, Single Fryer, w/lip
910-5018 Standard (use 910-5019 on Burger King fryers)
910-6545 Optional (without lip along flue opening)
823-3749 Burger King with Button Studs (used w/Item 4)
15 Flue Cap, 2-Fryer Battery
823-2540 Standard (use 823-2542 on Burger King fryers)
823-3536 Burger King with Button Studs (used w/Item 4)
16 Flue Cap, 3-Fryer Battery (use 823-2543 on Burger King fryers)
823-2541 Standard (use 823-2543 on Burger King fryers)
823-3537 Burger King with Button Studs (used w/Item 4)
17 823-2569 Flue Cap, 4-Fryer Battery
823-3538 Burger King with Button Studs (used w/Item 4)
18 900-5486 Support, Flue Cap
19 900-4253 Flue Cap Retaining Strip, Burger King
* 910-3557 Flue Deflector
20 Top Cap, Single Fryer
824-0404 Standard
824-0408 H50 side of H50/FB18 Battery
21 824-0405 Top Cap, Two-Fryer Battery
22 824-0406 Top Cap, Three-Fryer Battery
23 824-0407 Top Cap, Four-Fryer Battery
24 Control Panel Assembly, Single Fryer
806-4732SP Standard (see Note 1)
806-5363SP H50 side of H50/FB18 Battery
25 806-4733SP Control Panel Assembly, 2-Fryer Battery (see Note 2)
26 806-4734SP Control Panel Assembly, 3-Fryer Battery (see Note 3)
27 806-5018SP Control Panel Assembly, 4-Fryer Battery (see Note 4)
* 826-1379 Screw, #10 X ½-inch Philips Head (Pkg. of 10) (attaches top cap)
* 826-1371 Screw, #8 X ½-inch Hex Washer Head (Pkg. of 25) (attaches flue cap)
* Not illustrated.
NOTES:
1. Use 806-9712SP on KFC fryers; use 106-2927SP for units with fallback controllers.
2. Use 806-9713SP on KFC fryers; use 106-2928SP for units with fallback controllers.
3. Use 806-9714SP on KFC fryers; use 106-2929SP for units with fallback controllers.
4. Use 806-9715SP on KFC fryers.
