2-58
ITEM PART # COMPONENT
Full Vat Frypot Assembly, Complete (see Page 2-58 for P/Ns)
1 823-3316 Retainer, Lower Front Insulation, Right (before 09/01 use 200-0934)
2 823-3315 Retainer, Lower Front Insulation, Left (before 09/01 use 200-0935)
3 200-0936 Back, Combustion Chamber, Left
4 200-0937 Back, Combustion Chamber, Right
5 200-2227 Retainer, Upper Front Insulation
6 106-1019SP Flue Assembly, Full Vat (before 09/01 use 806-5859SP)
7 826-1372 Nut, ¼-20 Hex Head Grip (Pkg of 10)
8 826-1371 Screw, #8 x ½-inch Hex Head Drill Point (Pkg of 25)
9 809-0362 Screw, # 8 x 1¼-inch Hex Head Drill Point
10 826-1383 Washer, ¾-inch OD x ¼-inch ID Steel (Pkg of 5)
11 809-0804 Nut, ¼-20 Washer-Face Lock
12 810-0406 Spacer, ¼-inch x 1½
-
inch Long
13 826-1340 Spacer, ¼-inch x 1
3 /
16
-inch Long (Pkg of 10)
14 810-0500 Spacer, ¼-inch x 15 /
16
-inch Long
15 826-1072 Burner, Natural or Propane, Universal (use 826-1073 for Mfg gas)
16 812-0355 Insulation, Lower Rear
17 812-0356 Insulation, Sight Glass Gasket
18 816-0577 Insulation, Burner (½-inch x 36-inches)
19 812-0404 Insulation, Front Seal (for left and right)
20 812-0457 Insulation, Lower Front
21 812-0706 Insulation, Upper Burner Rail
22 812-0993 Insulation, Upper Oil Zone
23 812-1029 Insulation, Combustion Chamber Side
24 814-0048SP Sight Glass
25 816-0057 Gasket, Plenum Chamber
26 816-0560 Insulation, Upper Front
27 816-0561 Insulation, Combustion Chamber, Outer
28 823-0969 Plenum, Full Vat (for CE units, use 823-1048)
29 823-3304 Combustion Chamber Outer Front, Right (before 09/01 use 823-1169SP)
30 823-1777 Burner Rail, Left
31 Frypot, Full Vat (shown for assembly reference only)
32 823-3142 Burner Rail, Right
33 824-0863 Retainer, Left Front Seal Insulation
34 824-0864 Retainer, Right Front Seal Insulation
35 900-1031 Retainer, Sight Glass, ¾-inch
36 900-1049 Retainer, Plenum Chamber Gasket
37 900-1221 Retainer, Rear Insulation and Combustion Chamber Back
38 900-1515 Brace, Upper Oil Zone Insulation
39 900-4452 Retainer, Combustion Chamber Side Insulation
40 930-0818 Bracket, Flue to Frypot Connection
41 823-3305 Combustion Chamber Outer Front, Left (before 09/01 use 823-11691SP)
42 809-0500 Screw, #10 x ½-inch Hex Washer Head
43 900-4253 Strip, Fluecap Retainer
* 813-0156 Plug, ½-inch NPT BM (for blocking unneeded ports)
* 813-0336 Plug, ½-inch SS (for blocking unneeded ports)
* 910-2474 Pot-to-Pot Gap Clip
* 900-0857 Brace, Frypot to Cabinet
*Not illustrated.
