2-44
ITEM PART # COMPONENT
1 807-2484 Valve, Solenoid Vent
2 810-0278 Valve, ½-inch NPT Ball
3 810-1372 Fitting, ¼-inch NPT x 90º
4 810-1069 Flexline, Oil Return, 29.5-inch
5 810-1668 Adapter, ½-inch NPT Male (converts female to male)
6 810-1680 Flexline, Oil Return, 6.5-inch
7 813-0003 Tee, ½-inch NPT
8 813-0022 Nipple, ½-inch NPT x Close
9 813-0087 Nipple, ½-inch NPT x 1.5-inch
10 813-0156 Plug, ½-inch NPT
11 813-0247 Nipple, ½-inch NPT x 3.5-inch
12 813-0251 Nipple, ½-inch NPT x 4.5-inch
13 813-0537 Nipple, ¼-inch NPT x 2-inch
14 813-0555 Reducer, ½-inch to ¼-inch NPT
15 902-0883 Handle, Oil Return Valve (Right)
901-0883 Handle, Oil Return Valve (Left)
16 810-1057 Flexline, Oil Return, 13.0-inch
17 806-9437SP Flexline Assembly, Oil Return, 15.5-inch (2 of Item 5 plus Item 16)
18 810-1160 Flexline, Oil Return, 3.0-inch
19 813-0304 Reducer Bushing, ½-inch to ¼-inch NPT
20 813-0016 Nipple, ¼-inch NPT x Close
* 826-1720 Vent Tube, Teflon, ⅜-inch O.D. x 24-inches
* 811-0932 Vent Tube, Teflon, ⅜-inch O.D. per foot
* 816-0224 Insulation, Rubber 3-inch x 6-inch
NOTE: The following Oil Return Flexlines and miscellaneous components may also be used in some
specially configured units. When ordering a flexline, it is recommended that the line be measured (from
outside of flare fitting to outside of flare fitting) to ensure the correct item is ordered.
* 810-1160 Flexline, Oil Return, 3.0-inch
* 810-1339 Flexline, Oil Return, 4.5-inch
* 810-1159 Flexline, Oil Return, 5.0-inch
* 810-1067 Flexline, Oil Return, 8.5-inch
* 810-1043 Flexline, Oil Return, 9.5-inch
* 810-1055 Flexline, Oil Return, 11.5-inch
* 810-1369 Flexline, Oil Return, 17.5-inch
* 810-1068 Flexline, Oil Return, 21.5-inch
* 810-1069 Flexline, Oil Return, 29.5 inch
* 810-1056 Flexline, Oil Return, 52.5-inch
* 810-1669 Adapter, ½-inch NPT Female (converts male to female)
* 901-0883 Handle, Oil Return Valve (Left) (mirror of Item 15 above)
* 902-0883 Handle, Oil Return Valve (Right)
* Not illustrated
