1. MOUNTING, WIRING
12
3. Attach the bracket support to the rear of the display unit with the binding head screws (9 plac-
es).
4. Connect all cables at the back of the display unit. See section 1.7.
5. Loosen the knobs of the bracket support and set them in the notches on the mounting bracket.
6. Adjust the angle of the display unit and fix the knobs tightly.
Bracket Support
Binding Head Screw
Mounting Bracket (15)
Knob
