Furuno MU-150HD User Manual
Page 10
1. MOUNTING, WIRING
2
How to remove the hard cover
To attach the hard cover, follow the illustration in the figure below.
How to attach the hard cover
Cable running
Before you install the display unit, run all cables you use. See the interconnection diagram at the
back of this manual.
The upper edge of the hard cover
Pull forward the upper
edge by pressing here
with thumbs.
Hard cover
Cutout
Set the tabs on the top
of the hard cover to the
cutouts of the display
unit.
Tab
Push the tabs of the
bottom of the hard cover
strongly (2 places).
