Appendix A Event Notification Message List
A.2 Message List
ETERNUS DX60 S2 Disk storage system User’s Guide -Operation-
94
Copyright 2012 FUJITSU LIMITED P3AM-5512-03ENZ0
A.2.2 Error Messages
This section describes the messages that are sent when the severity is Error for each type of
event.
■ Error message list
●
When the event type is "P"
The following messages are sent when components fail or degrade or when a temperature
error is detected.
Event type
and event
code
SNMP Trap Upper: Message
Remarks Trap
No.
TrapItemID
Trap
Sensor
Info
Lower: Description
P 01SSMM00 2 0100MM00 - Controller Module#m(zz xxHz) Fault
<pppppppppppp ssssssssss rrrrr> These messages
are notified when
"Module was bro-
ken" is enabled for
Error Severity Level
in the event notifica-
tion setting.
They are not notified
during maintenance
operations.
CM is disconnected.
SS: Component subtype
MM: CM module ID (10 – 11)
m: CM number (0 – 1)
zz: Model name (FC4G, SAS, or iSCSI)
xx: CPU frequency (1.2GHz)
pp...: Component number
ss...: Serial number
rr...: Version
P 06SSMM00 2 0600MM00 - Controller Module#m(zz xxHz) BE Expander
Fault <pppppppppppp ssssssssss rrrrr>
CM EXP is disconnected.
SS: Component subtype
MM: CM module ID (10 – 11)
m: CM number (0 – 1)
zz: Model name (FC4G, SAS, or iSCSI)
xx: CPU frequency (1.2GHz)
pp...: Component number
ss...: Serial number
rr...: Version
P 08SSMM0p 2 0800MM0p - Controller Module#m(zz xxHz) DI Port#p Fault
<pppppppppppp ssssssssss rrrrr>
CM DI Port is disconnected.
SS: Component subtype
MM: CM module ID (10 – 11)
p: Port number (0 – 1)
m: CM number (0 – 1)
zz: Model name (FC4G, SAS, or iSCSI)
xx: CPU frequency (1.2GHz)
pp...: Component number
ss...: Serial number
rr...: Version
