Chapter 1 Components
1.2 Drive Enclosures
ETERNUS DX60 S2 Disk storage system User’s Guide -Operation-
23
Copyright 2012 FUJITSU LIMITED P3AM-5512-03ENZ0
1.2 Drive Enclosures
3.5" disks and LEDs are installed in the front of a 3.5" drive enclosure. Expanders and power
supply units are installed in the rear.
1.2.1 Front
●
With front cover
Figure 1.16 Front view of a drive enclosure (with front cover)
●
Without front cover
Figure 1.17 Front view of a drive enclosure (without front cover)
1.2.2 Rear
■ Single expander type
Figure 1.18 Rear view of drive enclosure (single expander model)
Operation panel
Front cover
3.5-inch disk
Operation panel
Power Supply Unit
(PSU#0)
Power Supply Unit
(PSU#1)
Expander (EXP#0) Cover
