61
3.5 Cleaning the Discharge Brush
3
D
A
IR
Y CARE
9. Attach a new Brake roller unit in the reverse order of its removal. Make sure that
the Brake roller unit is firmly installed.
10. Install the guide plate in the reverse order of the removal. You should push it
down then the installation can be done smoothly.
11. Lower the ADF upper sheet guide slowly.
12. Lift the Upper transport unit a little to release the safety lock and then lower the
transport unit slowly.
