D824/D1624 Reference Manual (MIDI Implementation Chart/MMC List)
sound data will be erased (data "0" is written in). However,
when sound data length in the clipboard is less than 10ms,
specifying the will be limited to "01."
Also, by specifying the , paste operation can be
executed on other tracks in mono (one track unit) or stereo
units (tracks 1-2, 3-4, 5-6, 7-8).
Since time corresponding to length of the move clipped sound
data is required to complete the move paste operation, D824/
D1624 will immediately reply with "32 4E ((active)>)" after receiving the command.
Following completion of the move paste operation, "32 4E (message = 01 (completed)>)" will be sent.
If paste cannot be executed due to improper figures of the
previously registered auto punch in point, insufficient disc ca-
pacity, no sound data is in the clipboard, etc., the correspond-
ing will be replied.
12 4F (): track exchange command
When the D824/D1624 receives this command, the track can
be exchange between the specified . Es-
pecially, if the first , then exchange
by grouping will be executed between channel 1-8 and chan-
nel 17-24, and if the next byte ,
then the exchange will be between channel 9-16 and channel
17-24. If it cannot be executed for some reason, an error mes-
sage will be sent back.
13 3E: product new program command
When the D824/D1624 receives this command, a new pro-
gram is compiled and the current program is transferred to
the new program. As compilation of the new program is com-
paratively short time, it is replied with "33 3E ((completed)>)" immediately upon completion of execution.
If it cannot be executed for some reason, an error message will
be sent back.
13 3F: delete current program command
When the D824/D1624 receives this command, the current
program is deleted and succeeding programs moved up and
renumberd. If the deleted program is the only tune existing in
the track, a new program will be made automatically.
As this delete current program is executed in a comparatively
short time, "33 3F ()" will be
sent back immediately upon completing the execution.
If it cannot be executed for some reason, an error message will
be sent back.
13 41 (): digital in ch.select command
The audio signal input from SPDIF digital in to assigned to the
destination track specified by . The first
shown in the command is the SPDIF L channel input, and the
second the R channel input. " nel =0>" indicates the normal analog input.
13 41 (): Adat in select com-
mand
Channel = 7F indicates that it is Adat In. Normally, it will be
"" and all channels will be inputs from Adat In.
If is indicates, then only the tracks
selected will be Adat In inputs. ""
indicates the normal analog input.
13 42 (): digital out ch.select command
The source channel for digital out is selected.
Normally, the first shown will be the SPDIF L chan-
nel data, and the second the SPDIF R channel out-
put. (<00><00>) is the default setting. By FDMS-3, any chan-
nel within "1 ~ 8" (or 8 ~ 16) can be selected.
13 42 (): Adat out select command
In a device which can be switched between SPDIF and Adat, if
the first display is , then Adat Out can be setup.
13 43(): program change command
The command for PROGRAM CHANGE of D824/D1624. The
present program number can be changed to the figure indi-
cated by .
13 44 (): click on/off command
The command for setting the metronome on/off of D824/
D1624. When ON is set, the metronome signal will be fed to
the track 8 output of D824, and the track 16 output of D1624.
13 46 (): Bar/Beat Resolution ON/OFF command
The command for ON/OFF of the bar/beat resolution function
of this equipments' current program.
13 47 (): Midi Sync Out command
The setup command for MIDI Sync Out mode of this equip-
ments' current program.
13 48 (): MTC offset mode command
The setup command for MTC offset mode of this equipments'
current program.
13 49 ( ): Vari pitch command
13 49 ( ): Vari pitch command
The command for setting this equipments' vari pitch ON/OFF
and pitch data.
Control of ON/OFF only is possible at and both ON/
OFF and pitch data can be set at .
14 01 (): Signature set command
The command for setting the meter of this equipment. If a new
data is registered at the bar position where a data exists, the
former data will be written over. When this command is re-
ceived, this equipment will reply with "34 01 ()."
Upon completing the registeration, will reply
with "01 (completed)," or with "10 (over value error)" if
registeration is attempted at a non-existing point or an errone-
ous figure is used.
14 02 (): Tempo set command
The command for tempo set of this equipment. If a new data is
registered in a bar/meter where data already exists, the former
data will be written over. When this command is received, this
equipment will reply with "34 02 ()." Upon
completing the registeration, will reply with
"01 (completed)," or with "10 (over value error)" if registeration
is attempted at a non-existing point or an erroneous figure is
used.
14 03 : Tempo map all erase command
When this command is received, this equipment will erase all
meter and tempo data in the current program and thus return
it to the default state (meter=4/4, tempo: =120). Also, when
this command is received, this equipment will reply with "34
