124
D824/D1624 Reference Manual (MIDI Implementation Chart/MMC List)
Fostex System Exclusive Message
General Structure=F0 51()F7
* Numbers are all expressed in hexadecimal units.
Table: ()
Command or Model Set Acknowledge or Status
Controller to D824/D1624 D824/D1624 to Controller
Loop on/off 12 22 ()
Post locate 12 28 ()
Auto rec 12 2D () 32 2D ()
Lock enable 12 41 ()
Lock mode 12 42 ()
Copy clip 12 45 () 32 45 ()
12 46 ()
Copy paste or 32 46 ()
12 46 ()
Erase 12 47 () 32 47 ()
Clipboard play 12 49 32 49 ()
Undo 12 4A 32 4A ()
Redo 12 4B 32 4B ()
Move clip 12 4D () 32 4D ()
12 4E ()
Move paste or 32 4E ()
12 4E ()
Move clip 12 4D () 32 4D ()
Move clip 12 4D () 32 4D ()
Move clip 12 4D () 32 4D ()
Move clip 12 4D () 32 4D ()
Digital in ch. 13 41 ()
Digital out ch. 13 42 () * Refer to Note.
Move clip 12 4D () 32 4D ()
Program change 13 43 ()
Click on/off 13 44 ()
Resolution on/off 13 46 ()
Midi Sync out 13 47 ()
MTC offset mode 13 48 ()
13 49 ()
Vari pitch or
13 49 ()
Signature set 14 01 () 34 00 ()
Tempo set 14 02 () 34 00 ()
Tempo map all erase14 03 34 00 ()
Preroll time set 14 04 ()
Frame rate set 14 06 ()
Time base set 14 08 ()
< N o t e > < N o t e > < N o t e > < N o t e > < N o t e >
Following protocol is effective only in equipment which will reply by -
Identity Reply=F0 7E06 02 51 01 00 10 00 ** ** ** ** F7 (D824)
Identity Reply=F0 7E06 02 51 01 00 11 00 ** ** ** ** F7 (D1624)
against the Inquiry Message=F0 7E06 01.
Fostex MIDI System Exclusive Message Format for D824/D1624
