D824/D1624 Reference Manual (MIDI Implementation Chart/MMC List)
Explanation on the Command/Mode Set
12 22 (): loop on/off command
The command for setting the "loop mode on/off" (=ON/OFF of
AUTO RTN) of D824/D1624. Default figure of the loop opera-
tion mode is "12=stop" and this cannot be changed.
12 28 (): post locate command
The command for setting the "post locate mode" (=ON/OFF of
AUTO PLAY) of D824/D1624. It will stop after locating if "post
locate mode=12." It will enter play after locating if "post locate
mode=15."
12 2D (): auto rec command
The command for setting "auto rec mode on/off" (=ON/OFF of
AUTO PUNCH) of D824/D1624. Upon receiving this command,
D-160 will immediately reply the operating condition by send-
ing "32 2D ()".
12 41 (): lock enable command
The command for setting "slave mode on/off" (setup menu) of
D824/D1624.
12 42 (): lock mode command
The command for setup of the slave mode (setup menu) when
this equipment is set to "slave mode on."
12 45 () : copy clip command
When this command is received, D-108 will copy (multiple num-
ber of tracks can be copied simultaneously) the sound data, as
data for copy paste, from the pre-registered clipboard-in point
to the clipboard-out point in the track specified by .
With completion of copying the data into the clipboard, D824/
D1624 will immediately reply with "32 45 ((completed)>)". If copy cannot be executed due to improper
figures of the pre-registered clipboard in/clipboard out points
or incorrect track section, the corresponding
will be returned.
12 46 (): copy paste command
12 46 (): copy paste com-
mand
When this command is received, D824/D1624 will paste the
sound data which has been copied into the clipboard, on the
same track from the pre-registered auto punch in point as the
starting point for the number of time specified by count>.
However, if the sound data length in the clipboard is less than
10ms, the specifying the will be limited to
"01." Also, by specifying , paste can be executed
on other tracks in mono (in one track units) or stereo units (in
combinations of tracks 1-2, 3-4, 5-6, 7-8).
Since time corresponding to length of the copy clipped sound
data is required to complete the copy paste operation, D824/
D1624 immediately replies with "32 46(tive)>)" after receiving the command.
Successively upon completing the paste operation, "32 46 (message=01(completed)>)" is transmitted.
If paste cannot be executed due to improper figures of the pre-
registered auto punch in point, insufficient disc capacity, no
sound data in the clipboard, etc., the corresponding sage> will be replied.
12 47 (): erase command
When this command is received, D824/D1624 will erase the
data (writes in "0" data) in the section from the pre-registered
auto punch in point through auto punch out point in the track
specified by . Since time corresponding to length
of the erase section is required to complete the erase opera-
tion, D824/D1624 will immediately reply by "32 47 (sage=02 (active)>)" after receiving the command.
After the completion of erase operation, "32 47 (sage=01 (completed)>)" will be transmitted.
If erase cannot be executed due to improper figures of the pre-
registered auto punch in point/auto punch out point, incor-
rect track section, etc., the corresponding will
be replied.
12 49: clipboard play command
When this command is received, D824/D1624 will playback
once from the head of the sound data copied in the clipboard
by the copy clip and move clip commands.
Immediately after receiving the command, D824/D1624 will
reply with "32 49 (track>)." The sound data track number is indicated by (mmc
track>.
Upon completion of playback, "32 49 (pleted) is sent and clipboard play is ended. If there is no sound
data in the clipboard, "32 49 ()"
will be sent and clipboard play operation will be interrupted.
12 4A: undo command
Upon receiving this command, D824/D1624 will revert to the
condition prior to editing copy paste,erase, move paste, cut,
redo operation. With completion of undo operation, D824/
D1624 will reply with "32 4A ()."
If D824/D1624 is not possible to undo, "32 4A (sage=00 (no message)>)" will be replied.
12 4B: redo command
When this command is received, D824/D1624 will return to
the condition prior to undo operation.
With completion of redo operation, D824/D1624 will reply
with "32 4B ()."
If D824/D1624 is not possible to redo, "32 4B ((no message)>)" will be replied.
12 4D (): move clip command
When this command is received, D824/D1624 will copy (mul-
tiple tracks can be copied simultaneously) the sound data from
the pre-registered clipboard in point to the clipboard out point,
as data for move paste operation. With completion copying
the data into the clipboard, D824/D1624 will immediately re-
ply with "32 4D ()." If copy
cannot be executed by the reason of pre-registered improper
clipboard in/clipboard out point figures or incorrect track sec-
tion, etc., the corresponding will be replied.
12 4E (): move paste command
12 4E (): move paste com-
mand
When this command is received, D824/D1624 will paste the
sound data which have been move
clipped in the clipboard,
for the number of times specified by on the
same track from the pre-registered auto punch in point as the
starting point. At the same time, the move clipped original
