Page 53
3.4 Jumper Settings
C141-E218
3-11
3.3.4 Power supply connector (CN1)
Figure 3.10 shows the pin assignment of the power supply connector (CN1).
Figure 3.10 Power supply connector pins (CN1)
3.4 Jumper Settings
3.4.1 Location of setting jumpers
Figure 3.11 shows the location of the jumpers to select drive configuration and
functions.
Figure 3.11 Jumper location
