Interface
5-58 C141-E218
(17) DEVICE CONFIGURATION (X'B1')
Individual Device Configuration Overlay feature set commands are identified by
the value placed in the Features register. The following table shows these
Features register values. If this command sets with the reserved value of Features
register, an aborted error is posted.
FR values Command
C0h DEVICE CONFIGURATION RESTORE
C1h DEVICE CONFIGURATION FREEZE
C2h DEVICE CONFIGURATION IDENTIFY
C3h DEVICE CONFIGURATION SET
00h-BFh, C4h-FFh Reserved
At command issuance (I-O register contents)
1F7
h
(CM) 1 0 1 1 0 0 0 1
1F6
h
(DH) x x x DV xx
1F5
h
(CH)
1F4
h
(CL)
1F3
h
(SN)
1F2
h
(SC)
1F1
h
(FR)
xx
xx
xx
xx
C0h/C1h/C2h/C3h
At command completion (I-O register contents)
1F7
h
(ST) Status information
1F6
h
(DH) x x x DV xx
1F5
h
(CH)
1F4
h
(CL)
1F3
h
(SN)
1F2
h
(SC)
1F1
h
(ER)
xx
xx
xx
xx
Error information
