Interface
5-80
C141-E218
Bit 14-8: Undefined
Bit 7:
Removable disk drive = 1
Bit 6:
Fixed drive = 1
Bit 5-3:
Undefined
Bit 2:
IDENTIFY DEVICE Valid = 0
Bit 1-0:
Reserved
*2 Word 1, 3, 6, 60-61
Word MHV2120AT MHV2100AT MHV2080AT MHV2060AT MHV2040AT
1
X ' 3FFF '
X ' 3FFF '
X ' 3FFF '
X ' 3FFF '
X ' 3FFF '
3
X ' 10 '
X ' 10 '
X ' 10 '
X ' 10 '
X ' 10 '
6
X ' 3F '
X ' 3F '
X ' 3F '
X ' 3F '
X ' 3F '
60-61
X ' DF94BB0 '
X ' BA52230 '
X ' 950F8B0 '
X' 6FC7C80'
X ' 4A85300 '
*3 Status of the Word 2 Identify information is shown as follows:
37C8h
The device requires the SET FEATURES sub-command after the
power-on sequence in order to spin-up. The Identify information
is incomplete.
738Ch
The device requires the SET FEATURES sub-command after the
power-on sequence in order to spin-up. The Identify information
is incomplete.
8C73h
The device requires the SET FEATURES sub-command after the
power-on sequence in order to spin-up. The Identify information
is incomplete.
C837h
The device requires the SET FEATURES sub-command after the
power-on sequence in order to spin-up. The Identify information
is incomplete.
Others Reserved
*4 Word 49: Capabilities
Bit 15-14: Reserved
Bit 13:
1= Support the standby timer the same as the ATA standard.
Bit 12:
Reserved
Bit 11:
1 = Supported
Bit 10:
0 = Disable inhibition
Bit 7-0:
Undefined
Bit 8:
1 = LBA Supported
Bit 9:
1 = DMA Supported
