FOCUS Enhancements MR-HD100 - Manual (Page 208)

Technical Specifications
MR-HD100 Media Recorder
188
Environment
• Operating Temperature: 0-40° C (32° -104°F)
• Storage Temperature: -20-60° C (-4° -140°F)
• Ambient Operating Humidity: Within 10% to 85% (relative
humidity)
• Shock (Drop Test): Operating 50cm / Non-operating 100cm
Power
• Main unit:
11 – 18V DC,
Low power consumption. less than 3W during record,
• Removable and rechargeable Li-Ion battery pack:
Capable of more than 3 hours of continuous record operation,
Battery charger built into the unit,
• Supplied external AC adapter with restraining mechanism,
• Accept/receive power via USB 2.0 port:
Maximum 2.5W (500mA),
Operation Only - Does Not Charge Battery,
• Power From External DC Battery Devices
The ability to charge the MR-HD100 battery when operating
using an external DC battery device is dependent on the load
placed on the MR-HD100.
Consider the following when using external DC battery devices
to power the MR-HD100. The typical external DC video device
is 12V or 14.4V.
Power Consumption Tables
No Battery Installed - no charging current
Volt- in No Dongle With Linksys Dongle Notes
14.4 V 0.238A (3.42W) 0.328A (4.72W) idle-LCD/Backlight at
max
12.0V 0.285A (3.42W) 0.398A (4.77W) idle-LCD/Backlight at
max
