There are 3 types of menu screens; navigation screens that guide the user down through the
menu topology, configuration screens that allow the user to turn functions ON and OFF, and
information screens that provide information on the status of the unit.
6.1 NAVIGATION SCREENS
Pressing the appropriate key activates its associated menu. There is no need to press
(In fact pressing will, in most cases, have the undesired effect of exiting the selected
screen).
Functions keys change as you change screens
Screen name Time and date
OM100 Mon 01 Nov 2002 00:38:20
Configuration Menu
Urgent Alarm:On Non-Urgent Alarm:Off
M Master/Slave
U User Port
P Protection Switching
R Reboot
S System
N Subsystem Names
O Monitoring
W Software
C Serial Communications
F Front Panel
Type selection: M
F1 Help F3 Previous Menu F4 Main Menu
