Fig. 2.16 – Brother HL-1060 User Manual
Page 31
CHAPTER II -15
1.6.2
High-voltage Power Supply, SR PCB
This generates and outputs the voltages and currents for the charging, development and
transfer functions.
Transfer Roller
Supply
Roller
Photosensitive
Drum
Developing
Roller
Cleaner
Roller
Corona
Unit
Current
Regulator
Current
Regulator
Voltage
Regulator
Voltage
Regulator
Voltage
Regulator
Voltage
Regulator
Voltage
Regulator
T101
Current
Regulator
24VI
T1
T601 Q602
T701 Q702
Z301
PC001
PAPER
SENSOR
VR301
VR401
VR501
VR201 VR202
24VI
GND
IP001
IC PROTECTOR
GND
24VI
GND
Fig. 2.16
