SRM-121/SRM-150 LCD Monitor
Page 10
1.2.6 Frame
An aluminum frame surrounds the SRM series LCD monitor. This aluminum frame has
small screw holes that are used to attach the LCD monitor to a rack mount kit for mounting
into a rack or cabinet. The screw holes on SRM-121 and SRM-150 are circled in Figure
1-7 and Figure 1-8.
Figure 1-7: SRM-121 Frame Rear View (10 rackmount kit screw holes)
Figure 1-8: SRM-150 Frame Rear View (12 rackmount kit screw holes)
