PPC-51xxA-G41/WIDS-51xA-G41 Panel PC
Page 78
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Super I/O Chipset
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Parallel Port Address
[378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Serial Port1 Address [3F8/IRQ4]
Serial Port1 Mode [Normal]
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
Serial Port3 Address [3E8]
Serial Port3 IRQ [11]
Serial Port4 Address [2E8]
Serial Port4 IRQ [10]
Serial Port5 Address [2D0]
Serial Port5 IRQ [11]
Serial Port6 Address [2E0]
Serial Port6 IRQ [10]
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 6: Super IO Configuration
Parallel Port Address [378]
Use the Parallel Port Address option to select the parallel port base address.
Disabled No base address is assigned to the Parallel Port
378 D EFAULT Parallel Port I/O port address is 378
278 Parallel Port I/O port address is 278
3BC Parallel Port I/O port address is 3BC
Parallel Port Mode [Normal]
Use the Parallel Port Mode option to select the mode the parallel port operates in.
Normal D EFAULT The normal parallel port mode is the standard mode
for parallel port operation.
Bi-directional Parallel port outputs are 8-bits long. Inputs are
accomplished by reading 4 of the 8 bits on the
status register.
