Software specifications, General, Oftware – IDEC SX5L Series User Manual
Page 36: Pecifications, Introduction

SX5L C
OMMUNICATION
T
ERMINAL
U
SER
’
S
M
ANUAL
4-1
4: S
OFTWARE
S
PECIFICATIONS
Introduction
This chapter describes the software specifications of the SX5L communication terminals. Designing a L
ON
W
ORKS
net-
work requires complete understanding of the functional blocks available on each SX5L communication terminal. Before
starting system configuration, read this chapter to understand available functional blocks.
General
The SX5L communication terminals contain an application program installed before shipment from factory. The functions
of application programs are configured in units of functional blocks. More than one functional block is installed in one
SX5L communication terminal. Available functional blocks are listed in the table below.
To set up a L
ON
W
ORKS
network, every device on the network, including the SX5L modules, must be commissioned indi-
vidually to assign an address using a network management tool. A Neuron ID is needed to identify each L
ON
W
ORKS
mod-
ule. While commissioning the SX5L using a network management tool, either enter the 12-digit alphanumeric Neuron ID
printed on the label on the SX5L manually, or press the SERVICE REQUEST button on the SX5L module to send the ser-
vice pin message.
Available Functional Blocks
Functional Block
Input
Module
Output
Module
I/O
Module
I/O
Start/Stop
Analog
Input
Pt100
Ω
Input
Pulse
Input
Remote-
control
Page
SBN16B1
SBT16K1
SBT16S1
SBM16K1
SBM16S1
SBM16K2
SBM16S2
SBAN041
SBPT04X1
SBPT04Y1
SBCN081
SBRR081
Node Object
x
x
x
x
x
x
x
x
Digital Input
x
x
Digital Output
x
x
Virtual I/O
x
x
Shot Output/Digital Input
x
Analog Input
x
Pt100
Ω Input
x
Pulse Count
x
Remote-control
Relay Control
x
Quantity of
Alias Table Entries
62
62
62
16
8
8
16
16
