138
6) Energy-Saving Function (Automatic Servo-Motor Turning OFF) Setting
Explained below is the case for 2-point stop as an example.
The procedure to turn off the motor power supply automatically (servo-motor automatically) 5.0
seconds after the machine stop, is described.
No. Operation Window Remarks
1 Touch Initial set in the MEC
MENU window.
2 Set the automatic
servo-motor OFF delay time.
Touch the Parameter.
3 Input a password. The password is set to
‘5119’ (at delivery).
The password can be
changed in ‘Password’ under
Environment Setting.
4 Touch the Parameter.
5 Touch direction arrow button
ĸ or ĺ to change the
window continuously and
display the automatic
servo-motor turning OFF
delay time setting window.
6 Touch the value.
7 Touch 5 and . When the value input is
stopped, touch ESC.
The value will not be set and
the previous position setting
window will be returned.
