130
No. Operation Window Remarks
7 Perform the home return
operation. Touching STOP stops the
home return operation.
8 If the motor power supply
(servo) is off, touch SON to
turn ON the motor power
supply (servo) on.
9 Touch Slow S or Fast F to
set the jog speed
10 Move the slider or rod using
the arrow button ĸ or ĺ to
align the actuator with the
target position "80.0mm".
11 Touch the Get .
12 Touch the ESC.
13 “80.00” is displayed in the
position data section. It is
confirmed that the position
data has been captured. Touching Tb1 return to the
Forward Position/Backward
Position setting window in
the Position Setting window.
