121
No. Operation Window Remarks
7 Touch the velocity value. Touching Tb1 return to the
Forward Position/Backward
Position setting window in
the Position Setting window.
8 Touch 5, 0, then . When the value input is
stopped, touch ESC.
The value will not be set and
the previous
“Position/Velocity setting
window” in the Position
Setting window will be
returned.
9 “50.00” is displayed in the
velocity data section.
Touching Tb1 return to the
Forward Position/Backward
Position setting window in
the Position Setting window.
10 Touch the ACC. Touching Tb1 return to the
Forward Position/Backward
Position setting window in
the Position Setting window.
11 Touch the acceleration
value. Touching Back returns to the
previous “Position/Velocity
setting window” in the
Position Setting window.
Touching MENU return to
the Forward Position
/Backward Position setting
window in the Position
Setting window.
12 Touch 0, . and 3 in order,
then . When the value input is
stopped, touch ESC.
The value will not be set and
the previous
“Position/Velocity setting
window” in the Position
Setting window will be
returned.
13 “0.30” is displayed in the
acceleration data section. Touching Back returns to the
previous “Position/Velocity
setting window” in the
Position Setting window.
Touching MENU return to
the Forward Position
/Backward Position setting
window in the Position
Setting window.
