Intermate 100 User Manual
Page 40
Intermate100 and Intermate101 Print Server Administration Manual
40
Windows NT 4.0: Native LPR
Type in the IP address or host name of the Intermate100 in
the “Name or address of...” field. If you use the host name,
a mapping of the name and IP address must be entered in
the hosts file. This is found in the directory
\
The definition of
operating system is installed and the name given to the top-
level folder. A typical
In the same box, enter a name for Print Queue.
If you have no special requirements, type in PAR_B.
This is a “binary” queue type which will print to Logical
Printer 0. See
“LPR Print Queues (LPD Protocol)” [page 163]
for information on permissible names and queue types.
Finish by pressing the |OK| button.
8
You will be returned to the Printer Ports dialog box, which
you will Close. This returns you to the listing of available
ports.
9
Choose the new port inserted in the list and click Next.
