IBM 8xx - Manual (Page 83)

Asm–
Index Part
Number
Units Description
26–1 1 Load cell. See 22–1 on page 55.
–2 Platen, carousel side shelf. See assembly 23– on page 57.
–3 41D9744 1 Carousel bag pack clamping plate
–4 41D8195 1 Lid tower, Models 151, 606, and 616 Carousel, round small
– 41D7621 1 Carousel assembly contains:
–5 v Platen, carousel round. See 23– on page 57.
–6 v Load cell, carousel. See 22–1 on page 55.
–7 41D8194 1 v Wheel assembly Models 151, 606, and 616 carousel, plastic
–8 44M1975 1 Kickplate, front/rear, for Models 151, 606, and 616 carousel
–9 44M1976 1 Kickplate, side, for Models 151, 606, and 616 carousel
–10 44M1977 1 Kickplate, shelf, for Models 151, 606, and 616 carousel
– 41D8185 1 Lower bushing kit, Models 151, 606, and 616 carousel (not shown)
– 41D8187 1 Carousel parts kit, contains - 4 M8x10 hex socket screws, 4 rubber buffers
30x25xM8, 1 grounding spring, 4 shims frolic 1026D, 4 Phil pan head screws NC
6x1", 8 M6x35 hex socket screws, 1 bearing, 8 socket head shoulder screws (M8),
1 upper bushing, 1 nylon locking nut, 1 plastic plug transparent
– 41D8190 1 Electrical interface box for Models 151, 606, and 616 carousel (not shown)
– 41D8192 1 Cable, Models 151, 606, and 616 carousel data communication (not shown)
– 41D8193 1 Power supply Models 151, 606, and 616 carousel, 120/9V external (not shown)
Assembly 26: (continued)
Updated October 16, 2007
Chapter 5. Bagging and Carousel Bagging 71
||||
||||
||||
||||
||||
||||
||||
||||
||||
