Asm–
Index Part
Number
Units Description
–18 41K6356 1 Cash cup, left hand
–18 41K6355 1 Cash cup, right hand
–18B 41D7080 1 Detector, cash cup
–18C 41D7082 1 Emitter, cash cup
–19 41J9838 1 Sensor card, cash cup
–20 1 Countertop. See “Assembly 18: Countertop” on page 44 for a complete listing of
available countertops.
–21 1 Signature capture device. See “Assembly 19: Signature Capture and Coupon
Acceptor” on page 46 for a complete listing of signature capture parts.
–22 41J9916 1 Proximity sensor
–23 40M9472 1 Proximity sensor cable
–24 1 Bill dispenser assembly. See “Assembly 2: Bill Dispenser” on page 6.
–25 41D9329 1 Hinge, upper hinge for right hand door (lower hinge for the left hand door)
–26 41K6087 1 Safe door cam lock
–27 41K6120 1 Safe door lock, currency lock with key. See Chapter 11, “Locks and Keys,” on page
95.
–28 41K6089 1 Safe door, right hand
–28 41K6090 1 Safe door, left hand
–29 41D9330 1 Hinge, lower hinge for the right hand door (upper hinge for the left hand door)
–30 41K6166 1 Bushing, hinge
–31 1 Keylock, cabinet lock with key. See Chapter 11, “Locks and Keys,” on page 95.
–32 41J9135 1 Security controller
–33 1 Lane PC. See “Assembly 21: Lane PC, Mouse, and Keyboard” on page 50.
–34 41D9359 1 Uninterruptible power supply, 230V/400W (BK650EI) (machines built after July 31,
2006)
–34 41D7068 1 Uninterruptible power supply, 115V (replaces 28R3582) (SU620)
– 44D0872 1 APC RBC4 Uninterruptible power supply replacement battery (for SU620)
– 44D0874 1 APC RBC5 Uninterruptible power supply replacement battery (for SU700INET)
– 44D1125 1 APC RBC17 Uninterruptible power supply replacement battery (for BK650EI)
(machines built after July 31, 2006)
–35 41K6161 1 Customer or basket shelf
–36 1 Sensormatic Scan Max Pro controller (shown for reference only)
–37 28R3587 1 Power strip, 5 Outlet, IEC320 (International, not US and Canada)
– 28R3595 1 Power strip, 115V, US, Canada, 8 outlet (not shown)
– 41D7775 1 Power strip IEC320 C-14 to 5 EU1-16R, French
– 44D0448 1 Power strip, IEC 60320 C-14 to 5 UK-13R
–38 41J9542 1 Filter/power box
–39 41E1865 1 Cover plate, lane light
–40 1 Cassette Coin dispenser. See “Assembly 9: Coin Dispensers” on page 20 for a
complete listing of coin dispenser parts.
–41 41J9891 1 Bracket for vacuum florescent (VF) display (for some fiscal printers)
– 40N4716 1 3.8m Printer USB cable (not shown)
– 41K6369 1 PC Audio cable (not shown)
– 41D7073 1 Cable, 6 foot, DB9, male/female, used for uninterruptible power supply data (not
shown)
– 41E1832 1 Power strip mounting plate (not shown)
– 28R3559 1 Power jumper cord, IEC 60320 C-14 to NEMA 5-15R (not shown)
– 39M5376 1 Power jumper cord, IEC320, 2-0M
– 41K6368 1 Power supply, Security controller (not shown)
– See Appendix A, “Cabinet Parts and Sensors,” on page 105 for available
cabinet FRUs.
– See Chapter 10, “Cables,” on page 89 for additional cable FRUs.
Assembly 1: (continued)
Updated October 16, 2007
4 Self Checkout 4845: Parts Manual Models 131, 15x, 171, 6xx, 8xx, and BW3
