Asm–
Index Part
Number
Units Description
6– See “How to Use This Parts Manual” on page v for general parts manual
information, including ordering parts. See “Identifying a Right Hand or Left Hand
Model” on page v for how to identify left hand and right hand models.
–1 41K6308 1 Lower unit timing belt
–2 41K6306 1 Lower unit gear 20 kit (includes 1 pin, 1 gear, 2 retaining E rings)
–3 41D7217 1 Lower unit gear 34 kit (includes 1 pin, 1 gear, 1 retaining E ring)
–4 41K6307 1 Lower unit gear 54 kit (includes 1 gear, 1 retaining ring)
–5 41D7121 1 Lower unit gear 44 kit (includes 1 pin, 1 gear, 1 retaining ring)
–6 41D7563 1 Bill dispenser sensor kit. See 5–4 on page 13.
–7 41D7125 1 Cassette sensor, bill dispenser
–8 41K6309 1 Cable assembly, lower unit
–9 41K6291 1 Timing kit, lower unit (includes 1 gear pulley, 2 retaining rings, 1 spring, 1 timing
belt)
Assembly 6: (continued)
Updated October 16, 2007
Chapter 1. Core Module 15
