Asm–
Index Part
Number
Units Description
22– See “How to Use This Parts Manual” on page v for general parts manual
information, including ordering parts. See “Identifying a Right Hand or Left Hand
Model” on page v for how to identify left hand and right hand models.
–1 41D7448 1 Load cell, 1 bag position (Model N54)
–1 41D7451 1 Load cell, Models 152, 153, 171, 602, 612, 603, 613, 800, 810 (replaces 41J8098)
–1 41D7453 1 Load cell, 100 KG, Models 171, 800, and 810 (for wide lane with 25 inch belt)
–1 41D8188 1 Load cell, Models 151, 606, and 616 Carousel
–1 41D7622 1 Load cell, Models 151, 606, and 616 secondary shelf
– 41D7621 1 Digital carousel weighting assembly with load cells, frame, platen, cables, control
box, Models 151, 606, and 616
– 41D8291 4 Screw, M6 X 55 (attaches load cell to conveyor) Models 171, 800, and 810
– 41J6930 2 Adapter bar, (attaches load cell to conveyor, for wide lane with 25 inch belt)
– 41J6934 2 Guide, load cell plastic, Models 171, 800, and 810 (for standard lane with 19 inch
belt)
– 41J7417 2 Guide, load cell plastic, Models 171, 800, and 810 (for wide lane with 25 inch belt)
– 41D7073 2 Cable, 6 foot, DB9, male/female, used for load cell extension
Assembly 22: (continued)
Updated October 16, 2007
Chapter 2. Load Cells, Platens, Plates, and Retaining Fences 55
||||
||||
||||
||||
||||
|
||||
||||
|
||||
