IBM 8xx - Manual (Page 15)

Asm–
Index Part
Number
Units Description
1– See “How to Use This Parts Manual” on page v for general parts manual
information, including finding and ordering parts. See “Identifying a Right
Hand or Left Hand Model” on page v for how to identify left hand and right
hand models.
–1 1 Hopper coin dispenser. See “Assembly 9: Coin Dispensers” on page 20 for a
complete listing of coin dispenser parts.
–2 40M9470 1 Cable, Reset Button
–3 40M9469 1 Button Assembly, Reset (on upper door behind monitor)
–4 41J9296 1 Monitor, IBM SurePoint Model 4820 - 5WN (USB with I/O support), pearl white
(BOSS) (machines built after July 31, 2006)
–4 40M9366 1 Monitor, IBM SurePoint Model 4820 - 5WN (USB with I/O support), pearl white
(BOSS)
–4 41J9298 1 Monitor, IBM SurePoint Model 4820 - 5WN (USB without I/O support), pearl white
(lane)
–4 41J9295 1 Monitor, IBM SurePoint Model 4820 - 5GN (USB with I/O support), iron gray
(RAP/BOSS)
–4 41J9297 1 Monitor, IBM SurePoint Model 4820 - 5GN (USB without I/O support), iron gray
(lane) (machines built after July 31, 2006)
–4 28R5455 1 Monitor, IBM SurePoint Model 4820 - 5GN (USB without I/O support), iron gray
(lane)
–4 44M1846 1 Monitor, IBM SurePoint Model 4820 - 5GN (RS232 touch I/O), iron gray (EMEA)
–4 44D1157 1 Monitor, flat, T115 TFT, Model 4942 - 15X, black
– 14J1054 1 3.8 cable, Analog video Monitor, IBM SurePoint Model 4820.
– 42M5667 1 3.8 cable, Analog video Monitor, IBM SurePoint Model 4820 (machines built after
July 31, 2006).
– 01L1637 1 3.8 cable, USB Touchscreen Monitor, IBM SurePoint Model 4820.
– 42M5632 1 3.8 cable, USB Touchscreen Monitor, IBM SurePoint Model 4820 (machines built
after July 31, 2006).
–5 40N6220 1 Magnetic stripe reader, pearl white (attaches to the 4820 display)
–5 40N6224 1 Magnetic stripe reader, iron gray (attaches to the 4820 display)
–6 1 Bill acceptor assembly. See “Assembly 11: Bill Acceptor” on page 26 for a complete
listing of bill acceptors and parts.
–7 See “Assembly 12: Printers TIx and TGx” on page 28.
–8 See “Assembly 12: Printers TIx and TGx” on page 28.
–9 41E1851 1 Cover plate if there is no pinpad (not shown)
–9 Magnetic strip reader mount and pin pad mounting. See “Assembly 16: Magnetic
stripe reader and pin pad mount” on page 40).
–10 1 Coin acceptor. See “Assembly 10: Coin Acceptor” on page 24 for a complete listing
of coin acceptors and parts.
–11 41E1849 1 SurePoint display hinge
–12 41E1850 1 Display mounting kit (includes 4 - shoulder washers, 8 - screws, 4 - M4 top inserts,
1 - spacer plate, 1 - limiter (right hand), and 1 - limiter (left hand).
–13 1 Scanner/scale (shown for reference only)
– 41D7211 1 Scanner Adapter plate, Fujitsu (customer furnished scanner)
–14 28R3786 1 Speaker
–14 41D7083 1 Speaker (machines built after July 31, 2006)
– 41K6370 1 Speaker Audio cable (not shown)
–15 1 Scanner/scale contrast label (shown for reference only)
–16 42K0356 1 Label, Cash Out, right hand
–16 42K0360 1 Label, Cash Out, left hand
–17 42K0358 1 Label, Coupon
–18 41J9839 1 Cash cup assembly, right hand
–18 41J9841 1 Cash cup assembly, left hand
