Asm–
Index Part
Number
Units Description
36– Be sure to specify whether you are ordering replacement parts for a left hand or a
right hand model. See “How to Use This Parts Manual” on page v for general parts
manual information, including ordering parts. See “Identifying a Right Hand or Left
Hand Model” on page v for how to identify left hand and right hand models.
–1 Upper door assembly (No part number assigned, custom color part)
–2 Cabinet Weldment (No part number assigned, custom color part)
–3 42K0056 1 Rear bumper
–5 42K0068 1 Gas spring stiffener plate
–9 41K6103 1 Cable retainer, hook and loop
–10 Exterior access panel (No part number assigned, custom color part)
– 41K6165 1 Access panel thumbscrew/retainer (not shown)
–11 41K6164 1 Drip pan tubing
–12 41K6600 1 Cable, basket shaft
–13 41K6148 1 Cable basket bracket
–15 41K6150 1 Front/rear kick plate
–17 41K6149 1 Left/right kick plate
–19 41D7344 1 Leveler (replaces 39Y0601)
–20 12R9478 1 Caster, swivel
–22 41K6167 1 PC access door assembly, right hand
–22 41K6168 1 PC access door assembly, left hand
–23 Lower door assembly, cash module (No part number assigned, custom color part)
–24 41K6154 1 Accessory shelf, right hand
–24 41K6155 1 Accessory shelf, left hand
–25 41K6156 1 PC/Uninterruptible power supply shelf bracket
–26 41K6162 1 Drip pan, right hand
–26 41K6163 1 Drip pan, left hand
–27 Upper countertop assembly (see “Assembly 18: Countertop” on page 44 for a
complete listing of available countertops)
–29 42K0057 1 Scanner hood
–30 41K6151 1 Upper door cover stop, right hand
–30 41K6152 1 Upper door stop cover, left hand
–30A 41K6153 1 Upper door cover stop nut
–31 42K0051 1 Gas spring
–32 41K6157 1 Bumper, front
– 41K6159 1 Bumper gasket (not shown)
–40 41K6102 1 Upper door hinge (includes fasteners)
–41 41K6106 1 Lower door, coupon box assembly
– 41K6108 1 Lower door keyboard retaining bracket (not shown)
–42 41K6140 1 PC/uninterruptible power supply shelf, right hand
–42 41K6141 1 PC/uninterruptible power supply shelf, left hand
–43 41K6083 1 Drawer pull
–44 41K6142 1 Velcro strap for uninterruptible power supply
–45 41K6144 1 Cable basket, short, right hand
–45 41K6146 1 Cable basket, short, left hand
–46 41K6143 1 Cable basket, long, right hand
–46 41K6145 1 Cable basket, long, left hand
–47 44M1961 Lower door welded hinge pin, right hand
–47 44M1959 Lower door welded hinge pin, left hand
–48 41J6659 1 Lower door hinge spacer plate (not shown)
– 41K6595 1 Door stop, lower (not shown)
– 41D8382 1 Adjuster, lower door, RH (not shown)
– 41D8383 1 Adjuster, lower door, LH (not shown)
– 41K6572 1 Upper door cable cover (not shown)
Assembly 36: (continued)
Updated October 16, 2007
Appendix A. Cabinet Parts and Sensors 107
