Asm–
Index Part
Number
Units Description
9– See “How to Use This Parts Manual” on page v for general parts manual
information, including ordering parts. See “Identifying a Right Hand or Left Hand
Model” on page v for how to identify left hand and right hand models.
– 41D7047 1 Hopper coin dispenser, UK (includes assembly index # 1 ,9, 10, 11 and the base)
– 44D1294 1 Hopper coin dispenser, Euro (includes assembly index # 1 ,9, 10, 11 and the base)
– 41D7043 1 Hopper coin dispenser, US (includes assembly index # 1 ,9, 10, 11 and the base)
– 41D7045 1 Hopper coin dispenser, Canada (includes assembly index # 1 ,9, 10, 11 and the
base)
– 41D7051 1 Hopper coin dispenser, Australia (includes assembly index # 1 ,9, 10, 11 and the
base)
–1 41J7615 1 Hopper, coin dispenser, US/Canada .01
–1 41J7616 1 Hopper, coin dispenser, US/Canada .05
–1 41J7617 1 Hopper, coin dispenser, US/Canada .10
–1 41J7618 1 Hopper, coin dispenser, US/Canada .25
–1 41J7619 1 Hopper, coin dispenser, US/Canada 1.00
–1 41J7620 1 Hopper, coin dispenser, Canada 2.00
–1 41J7621 1 Hopper, coin dispenser, UK .01
–1 41J7622 1 Hopper, coin dispenser, UK .02
–1 41J7623 1 Hopper, coin dispenser, UK .05
–1 41J7624 1 Hopper, coin dispenser, UK .10
–1 41J7625 1 Hopper, coin dispenser, UK .20
–1 41J7626 1 Hopper, coin dispenser, UK 1.00
–1 41J7627 1 Hopper, coin dispenser, Euro .01
–1 41J7628 1 Hopper, coin dispenser, Euro .02
–1 41J7629 1 Hopper, coin dispenser, Euro .05
–1 41J7630 1 Hopper, coin dispenser, Euro .10
–1 41J7631 1 Hopper, coin dispenser, Euro .20
–1 41J7632 1 Hopper, coin dispenser, Euro .50
–1 41J7633 1 Hopper, coin dispenser, Euro 1.00
–1 41J7634 1 Hopper, coin dispenser, Euro 2.00
–2 41K6082 1 Hopper mount assembly, right hand (includes slide rails)
–2 41K6086 1 Hopper mount assembly, left hand (includes slide rails)
–3 1 Keylock. See Chapter 11, “Locks and Keys,” on page 95.
–4 41D7076 1 Reject plate, coin, right hand
–4 41D7078 1 Reject plate, coin, left hand
–5 41K6363 1 Chute, coin, right hand, for both hopper and cassette coin dispensers
–5 41K6364 1 Chute, coin, left hand, for both hopper and cassette coin dispensers
–6 41D7813 1 Upper coin chute assembly, right hand
–6 41D7815 1 Upper coin chute assembly, left hand
–8 41K6088 1 Lock, cam
–9 41J7638 1 Hopper coin dispenser rotor, US/Canada .01
–9 41J7639 1 Hopper coin dispenser rotor, US/Canada .05
–9 41J7640 1 Hopper coin dispenser rotor, US/Canada .10
–9 41J7641 1 Hopper coin dispenser rotor, US .25, UK .10
–9 41J7642 1 Hopper coin dispenser rotor, US/Canada 1.00
–9 41J7643 1 Hopper coin dispenser rotor, Canada 2.00
–9 41J7644 1 Hopper coin dispenser rotor, UK .01
–9 41J7645 1 Hopper coin dispenser rotor, UK .02
–9 41J7646 1 Hopper coin dispenser rotor, UK .05
–9 41J7648 1 Hopper coin dispenser rotor, UK .20 Euro .05
–9 41J7649 1 Hopper coin dispenser rotor, UK 1.00
–9 44D1296 1 Hopper coin dispenser rotor, Euro .01
–9 41J7651 1 Hopper coin dispenser rotor, Euro .02/.10
Assembly 9: (continued)
Updated October 16, 2007
Chapter 1. Core Module 21
