Asm–
Index Part
Number
Units Description
10– See “How to Use This Parts Manual” on page v for general parts manual
information, including ordering parts. See “Identifying a Right Hand or Left Hand
Model” on page v for how to identify left hand and right hand models.
–1 41D9345 1 Coin Acceptor, MEI CF9520, US, with side reject plate (part 10–2) (machines built
after July 31, 2006)
–1 41D8051 1 Coin Acceptor MEI, CF9520, US, rejects $0.01, with side reject plate (part 10–2)
(machines built after July 31, 2006)
–1 41J6735 1 Coin Acceptor MEI, CF9520, US, with side reject plate (part 10–2)
–1 41D9347 1 Coin Acceptor, MEI CF9520, UK, with side reject plate (part 10–2) (machines built
after July 31, 2006)
–1 41J6736 1 Coin Acceptor MEI, CF9520, UK, with side reject plate (part 10–2)
–1 41D9346 1 Coin Acceptor, MEI CF9520, Canada, with side reject plate (part 10–2) (machines
built after July 31, 2006)
–1 41J6737 1 Coin Acceptor, Canada, with side reject plate (part 10–2)
–1 41D9348 1 Coin Acceptor, MEI CF9520, Euro, with side reject plate (part 10–2) (machines built
after July 31, 2006)
–1 41J6738 1 Coin Acceptor, Euro, with side reject plate (part 10–2)
–1 41D9349 1 Coin Acceptor, MEI CF9520, Australian, with side reject plate (part 10–2) (machines
built after July 31, 2006)
–1 41J6739 1 Coin Acceptor, MEI CF9520, Australian, with side reject plate (part 10–2)
–2 41J8231 1 Coin acceptor side reject plate
–3 28R3292 1 Coin acceptor mounting plate
–4 42K0052 1 Cash acceptance bezel, right hand
–4 42K0053 1 Cash acceptance bezel, left hand
–5 42K0355 1 Label, cash in, right hand
–5 42K0359 1 Label, cash in, left hand
–6 41K6593 1 Shaft, cash acceptance bezel
–7 41J8076 1 Coin deflector, right hand
–7 42K0058 1 Coin deflector, left hand
–8 44D0245 1 Coin tray guide, right hand
–8 44D0246 1 Coin tray guide, left hand
–9 41K6160 1 Coin tray
–10 41K6363 1 Chute, coin RH
–10 41K6364 1 Chute, coin LH
– 28R5566 1 Ferrite core (installed on signal cable)
– 41K6354 1 Coin acceptor cable, US/Canada (not shown)
– 41K6359 1 Coin acceptor cable, EMEA/Australia (not shown)
Assembly 10: (continued)
Updated October 16, 2007
Chapter 1. Core Module 25
