Asm–
Index Part
Number
Units Description
2– See “How to Use This Parts Manual” on page v for general parts manual
information, including ordering parts. See “Identifying a Right Hand or Left Hand
Model” on page v for how to identify left hand and right hand models.
–1 41E1866 1 Bracket assembly, bill dispenser presenter mounting
–2 41K6318 1 Mount, bill dispenser (remains in cabinet)
–3 41K6319 1 Presenter, bill dispenser
–3A 41D7135 1 Sensor prism, presenter
–4 41D7137 1 Gear train, presenter gears
–5 41D7139 1 Presenter sensor plate
–6 41D7213 1 Bill dispenser, universal, 2 bin
–7 41D7053 1 Cartridge, universal, bill dispenser (includes configuration instructions and labels for
each currency). See “Assembly 7: Bill Dispenser Cassette” on page 16 for
additional component details.
–8 41D7215 1 Additional denomination module
–9 41K6398 1 Slide assembly, bill dispenser (with counter weight)
–10 41K6399 1 Mount parts, bill dispenser (pivot, screws, latch spring)
–11 41D8199 1 Set screw, bill dispenser presenter mount
– 41D7123 1 Presenter unit cable assembly (not shown)
– 41D7127 1 Presenter unit exit sensor (not shown)
