Asm–
Index
Part
Number
Units
Description
31–
The
illustration
shown
here
is
for
reference
only.
There
is
a
tag
on
each
cable
that
contains
the
part
number
for
that
cable.
When
ordering
replacement
cables
reference
the
part
number
on
the
tag
of
the
failing
or
broken
cable.
–
See
for
general
parts
manual
information,
including
ordering
parts.
See
for
how
to
identify
left
hand
and
right
hand
models.
–1
NA
1 Scanner/scale
(optional)
(SA)
(Supplied
by
the
scanner/scale
manufacturer)
–2
41D7073
1 RS-232
Security
scale
(SD)
Cable,
6
foot,
DB9,
male/female
–3
40M9472
1 Proximity
sensor
to
security
controller
(PRX)
–4
41E1831
1 Coupon
detector
to
security
controller
(CPN)
–5
41E1830
1 Coupon
detector
to
coupon
indicator
LED
–6
40M9400
1 Bill
dispenser
RS232
cable
(BLD)
–7
NA
1 Transaction
awareness
light
(TAL)
(comes
as
part
of
the
light
assembly)
–8
40M9470
1 Reset
button
(RX)
–9
41K6368
1 Security
controller
DC
power
(DCI)
with
power
supply
–10
NA
1 Lane
light
(optional)
(LLT)
(comes
as
part
of
the
light
assembly)
–11
28R3565
1 Power
input
from
uninterruptible
power
supply
cable
(UPI)
–12
28R3559
1 Uninterruptible
power
supply
power
output
to
device
power
strip
(UPO)
IEC60320
to
C14
Adapter
–13
28R3559
1 Main
power
output
(MAO)
–14
28R3589
1 Main
power
input
from
power
filter
box
(MAI)
–15
40M9423
1 Capacitor
box
(CVB)
–16
41D7073
1 To
curtain
emitter
(DE1)
Cable,
6
foot,
DB9,
male/female
–17
41D7073
1 To
curtain
detector
(DD1)
Cable,
6
foot,
DB9,
male/female
–18
41D7073
1 Security
scale
front
load
cell
(DW1)
Cable,
6
foot,
DB9,
male/female
–19
41D7073
1 Security
scale
rear
load
cell
(DW2)
Cable,
6
foot,
DB9,
male/female)
–20
44D1165
1 Sensormatic
control
cable
–21
41E1619
1 Splitter
cable
to
uninterruptible
power
supply
and
sensors
(DSU)
–22
41D7073
1 Cable
to
uninterruptible
power
supply
from
splitter
cable
–22
41D9361
1 240V
Cable
to
uninterruptible
power
supply
from
splitter
cable
–23
41J7731
1 USB
to
lane
PC
(USB1)
–24
41K6352
1 Coin
dispenser
data
cable
(DB9
on
one
end,
RJ45
on
other)
–25
41K6365
1 Cash
cup
(DPK)
–
44M1643
1 Cash
cup
detector
cable
(not
shown)
–
41J9835
1 Cash
cup
emitter
cable
(not
shown)
–26
28R3684
1 Bill
acceptor
(BLA)
–27
41K6354
1 Coin
acceptor
cable,
US/Canada
–27
41K6359
1 Coin
acceptor
cable,
EMEA/Australia
–28
41K6370
1 Audio
out
to
speaker
(OUT)
–29
41K6369
1 Audio
to
lane
PC
(IN)
–
41D7072
1 10'
Ethernet
CAT5
cable
–
41D7075
1 5'
Ethernet
CAT5
cable
–
41D7073
1 ELO
touchscreen
Cable,
6
foot,
DB9,
male/female
–
41J7452
1 Cable
harness
loop
style
Assembly
31:
(continued)
Updated
October
16,
2007
Chapter
10.
Cables
91
