IBM 8xx - Manual (Page 123)

Asm–
Index Part
Number
Units Description
37– Be sure to specify whether you are ordering replacement parts for a left hand or a
right hand model. See “How to Use This Parts Manual” on page v for general parts
manual information, including ordering parts. See “Identifying a Right Hand or Left
Hand Model” on page v for how to identify left hand and right hand models.
–1 Tower (a single welded assembly, the front curtain support). See 24–30 on page
62.
–2 Tower cap. See 24–32 on page 62.
–3 Curtain detector assembly. See 24–32 on page 62 for detector/emitter FRU
number.
–4 Curtain emitter assembly. See 24–32 on page 62 for detector/emitter FRU number.
–5 Tower cap. See 24–32 on page 62.
–6 Tower, rear curtain support. See 24–33 on page 62.
–7 Channel support
–8 Support bracket
–9 Access door assembly
–10 Wide rail
–11 Upper cabinet console
–12 Front bulkhead
–13 Lower panel
–14 Rear bulkhead
–15 Leveler lock nut
–16 Leveler
–17 Lower cabinet
–18 Cover plate
–19 Transport section door (no FRU number given, custom color part)
–20 41K6382 1 Hex key cam lock
–21 Security module lower access door (no FRU number given, custom color part)
–22 41K6382 Hex key cam lock
–23 Trash tray
–24 Cover plate
–25 Lower door panel
–26 Transport conveyor access panel (no FRU number given, custom color part)
–27 Security conveyor access panel (no FRU number given, custom color part)
–28 Bulkhead assembly
–29 Narrow rail (shopper side)
Assembly 37: (continued)
Updated October 16, 2007
