Asm–
Index Part
Number
Units Description
38– Be sure to specify whether you are ordering replacement parts for a left hand or a
right hand model. See “How to Use This Parts Manual” on page v for general parts
manual information, including ordering parts. See “Identifying a Right Hand or Left
Hand Model” on page v for how to identify left hand and right hand models.
–1 44D1363 1 Side bumper assembly
–2 Side kickplate
–3 1 Side access cover (no FRU number given, custom color part)
–4 44D1151 2 Corner bumper connector bracket (one on each side)
–5 44D0859 2 Front/rear kickplate
–6 2 Front/back cover (no FRU number given, custom color part)
–7 44D1365 1 Front bumper assembly
– 44D1366 1 Rear bumper assembly (not shown)
– 41K6382 1 Hex key cam lock
– 1 Lane light mounting clamp (not shown, used when lane light assembly is mounted
to the Models 152, 602, and 612 bagging module). See 20– on page 49 for FRU
number.
– 1 Lane light mounting strap (not shown, used when lane light assembly is mounted to
the Models 152, 602, and 612 bagging module). See 20– on page 49 for FRU
number.
Assembly 38: (continued)
Updated October 16, 2007
Appendix A. Cabinet Parts and Sensors 113
||||
|
|
||||
|
|
