Asm–
Index Part
Number
Units Description
24– See “How to Use This Parts Manual” on page v for general parts manual
information, including ordering parts. See “Identifying a Right Hand or Left Hand
Model” on page v for how to identify left hand and right hand models.
– 41J7432 1 Security conveyor assembly, 19 in., 115V
– 41J7436 1 Security conveyor assembly, 19 in., 230V
– 41J7440 1 Security conveyor assembly, 25 in., 115V
– 41J7444 1 Security conveyor assembly, 25 in., 230V
–1 41J8791 1 Skid plate (for standard lane with 19 inch belt)
–1 41J8896 1 Skid plate (for wide lane with 25 inch belt)
–2 41J9127 1 Plate, front transition, with sensors (for standard lane with 19 inch belt)
–2 41J8340 1 Plate, front transition, with sensors (for wide lane with 25 inch belt)
–2 41J8848 1 Plate, front transition (for wide lane with 25 inch belt) (includes support bracket)
–3 41D9782 1 Card stop bracket (mounted under the transition plate) (for standard lane with 19
inch belt)
–3 41J8867 1 Card stop bracket (mounted under the transition plate) (for wide lane with 25 inch
belt)
–4 41J9312 1 Motorized pulley, 19" security conveyor 115V-60hz, balanced
–4 41D9816 1 Motorized pulley, 19" security conveyor 230V-50hz, balanced
–4 41J9320 1 Motorized pulley, 25" security conveyor 115V-60hz, balanced
–4 41D9822 1 Motorized pulley, 25" security conveyor 230V-50hz, balanced
–5 28R3196 1 Guide, tracking, nose end (order with 28R3195). Adhesive plastic sticker. Reduces
friction between belt and metal sides.
–6 28R3298 1 Roller, idler (for standard lane with 19 inch belt)
–6 28R3275 1 Roller, idler (for wide lane with 25 inch belt)
–7 28R3284 2 Angle adjuster (one on each side)
–8 28R3285 2 Drive roller retaining angle (one on each side)
–9 41J7666 2 Bracket, drive isolation. Large black coupling. Use to adjust and isolate motor. (one
on each side)
–10 28R3283 2 Block, idler roller (one on each side)
–11 41J9845 1 Emitter, flat pack sensor assembly, replaces 40M9507, (Flat pack sensor
assemblies for the emitter and detector should be replaced as a set. Order
41J9849 detector.)
–12 41J9845 1 Exit sensor emitter (for standard lane with 19 inch belt)
–12 41J8344 1 Exit sensor emitter (for wide lane with 25 inch belt)
– 41J8854 1 Sensor cable, transition plate (not shown)
–13 41J8850 1 2nd emitter mounting bracket
–14 41D9783 1 Exit sensor mounting bracket
–15 28R3191 1 Plate, conveyer, left side (for standard lane with 19 inch belt)
–15 28R3277 1 Plate, conveyer, left side (for wide lane with 25 inch belt)
–16 28R3194 1 Guide, tracking, motor end (order with 28R3197). Adhesive plastic sticker. Reduces
friction between belt and metal sides.
–17 28R3192 1 Belt, security conveyor, with roller (for standard lane with 19 inch belt)
–17 28R3278 1 Belt, security conveyor, with roller (for wide lane with 25 inch belt)
–18 41J8338 1 Crossbar, conveyor frame (for standard lane with 19 inch belt) Aluminum bar.
(Replaces 28R3180)
–18 28R3279 1 Crossbar, conveyor frame (for wide lane with 25 inch belt)
–19 41J7448 1 Nose bar assembly (for standard lane with 19 inch belt)
–19 41J7450 1 Nose bar assembly (for wide lane with 25 inch belt)
–20 28R3195 1 Guide, tracking, motor end (order with 28R3196). Adhesive plastic sticker. Reduces
friction between belt and metal sides.
–21 28R3190 1 Plate, conveyer, right side (for standard lane with 19 inch belt)
–21 28R3276 1 Plate, conveyer, right side (for wide lane with 25 inch belt)
–22 28R3172 1 Nose bar angle adjuster
Assembly 24: (continued)
Updated October 16, 2007
Chapter 3. Security Conveyor 61
