Asm–
Index Part
Number
Units Description
13– Printer, right hand iron gray
–1 41J9452 1 Bracket, mounting Catalina printer, iron gray
–2 41J9533 1 Mounting bracket Catalina printer, right hand, iron gray (used with 41J9523)
–3 1 Catalina printer (customer furnished)
–4 41J9457 1 Hole cover, oval, iron gray
–5 1 Printer, TF6 and TM6. See IBM 4610 SureMark Printers Hardware Service Manual,
GY27-0355.
–6 41J9513 1 Printer shelf, 4610-TF6/TM6, right hand, iron gray
–7 41J8809 1 Rivet, black push in
–8 41J9538 1 Back cover, Catalina printer, iron gray (used with 41J9513)
–9 41J9770 1 Hole cover, round, iron gray
–10 41J9523 1 Auxiliary mount bracket Catalina printer, right hand, iron gray (used with 41J9513)
– 41D9653 1 Support bracket Catalina printer, iron gray
– Printer, right hand pearl white
–1 41J9454 1 Bracket, mounting Catalina printer, pearl white
–2 41J9535 1 Mounting bracket Catalina printer, right hand, pearl white (used with 41J9525)
–3 1 Catalina printer (customer furnished)
–4 41J9459 1 Hole cover, oval, pearl white
–5 1 Printer, TF6 and TM6. See IBM 4610 SureMark Printers Hardware Service Manual,
GY27-0355.
–6 41J9515 1 Printer shelf, 4610-TF6/TM6, right hand pearl white
–7 41J8807 1 Rivet, off white push in
–8 41J9540 1 Back cover, Catalina printer, pearl white (used with 41J9515)
–9 41J9772 1 Hole cover, round, pearl white
–10 41J9525 1 Auxiliary mount bracket Catalina printer, right hand, pearl white (used with 41J9515)
– 41D9655 1 Support bracket, Catalina printer, pearl white
– Printer, left hand iron gray
–1 41J9452 1 Bracket, mounting Catalina printer, iron gray
–2 41J9533 1 Mounting bracket Catalina printer, left hand, iron gray (used with 41J9528)
–3 1 Catalina printer (customer furnished)
–4 41J9457 1 Hole cover, oval, iron gray
–5 1 Printer, TF6 and TM6. See IBM 4610 SureMark Printers Hardware Service Manual,
GY27-0355.
–6 41J9518 1 Printer shelf, 4610-TF6/TM6, left hand iron gray
–7 41J8809 1 Rivet, black push in
–8 41J9538 1 Back cover, Catalina printer, iron gray (used with 41J9518)
–9 41J9770 1 Hole cover, round, iron gray
–10 41J9528 1 Auxiliary mount bracket Catalina printer, left hand, iron gray (used with 41J9518)
– 41D9653 1 Support bracket Catalina printer, iron gray
– Printer, left hand pearl white
–1 41J9454 1 Bracket, mounting Catalina printer, pearl white
–2 41J9535 1 Mounting bracket Catalina printer, left hand, pearl white (used with 41J9530)
–3 1 Catalina printer (customer furnished)
–4 41J9459 1 Hole cover, oval, pearl white
–5 1 Printers, TF6 and TM6. See IBM 4610 SureMark Printers Hardware Service
Manual, GY27-0355.
–6 41J9520 1 Printer shelf, 4610-TF6/TM6, left hand pearl white
–7 41J8807 1 Rivet, off white push in
–8 41J9540 1 Back cover, Catalina printer, pearl white (used with 41J9520)
–9 41J9772 1 Hole cover, round, pearl white
Assembly 13: (continued)
Updated October 16, 2007
Chapter 1. Core Module 33
