4 . Remove the USB/power connector board (5) and cable from the base enclosure.
Reverse this procedure to install the USB/power connector board.
System board
Description Spare part number
System board (includes replacement thermal material) 459251-001
Before removing the system board, follow these steps:
1 . Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2 . Disconnect all external devices connected to the computer.
3 . Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4 . Remove the battery (see Battery on page 36 ).
5 . Remove the following components:
a . Hard drives (see Hard drives on page 41 )
b . Optical drive (see Optical drive on page 47 )
c . Switch cover (see Switch cover on page 49 )
d . Keyboard (see Keyboard on page 53 )
e . Speaker assembly (see Speaker assembly on page 51 )
f . Display assembly (see Display assembly on page 55 )
g . Top cover (see Top cover on page 61 )
