HP PAVILION DX6500 - Manual (Page 51)

Memory module
Description Spare part number
2048-MB (PC2-5300, 667-MHz, DDR2) 453774-001
1024-MB (PC2-5300, 667-MHz, DDR2) 446495-001
512-MB (PC2-5300, 667-MHz, DDR2) 446494-001
Before removing the memory module, follow these steps:
1 . Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2 . Disconnect all external devices connected to the computer.
3 . Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4 . Remove the battery (see Battery on page 36 ).
Remove the memory module:
1 . Position the computer with the front toward you.
2 . Loosen the two Phillips PM2.5×5.0 screws (1) that secure the memory/WLAN module compartment
cover to the computer.
3 . Lift the rear edge of the cover (2), swing it up and forward, and remove the cover. The memory/
WLAN module compartment cover is included in the Plastics Kit, spare part number 438368-001.
4 . Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.
(The edge of the module opposite the slot rises away from the computer.)
Component replacement procedures 43
