-9- 595-4514-13
OFF
N O
AUT
O
ADJUSTMENT
T I M E L I G H T
+ +
Dark Any Light Level
5 Seconds
20 Minutes
Press in with screwdriver.
Swing out cover to remove.
The sensor can be prevented from turning on lights when there is
already enough light in the room. Use a small screwdriver to set the
light level using this diagram as a guide. In the fully clockwise
position, the sensor turns on lights even in full daylight. In the fully
counter-clockwise position, the sensor only turns on lights when
the surrounding light level is very low.
❐
With the switch in the AUTO position and the light at the desired
level for the lights to turn on, put the LIGHT control to the
minimum dark (fully counter-clockwise) position. Wait for the
lights to turn off.
❐
Move your hand in front of the sensor. While moving your hand
in front of the sensor, slowly turn the LIGHT adjustment clock-
wise until the lights controlled by the sensor come on.
PHOTO SENSITIVITY
