2.2.3
Connecting a VCR/ STB/ DVD Player Using
Component Video
Connect the TV to a VCR/ STB/ DVD player using the component video inputs.
2.2.4
Connecting a VCR/ STB/ DVD Player Using
Composite Video
Connect the TV to a VCR/ STB/ DVD player using the composite video input.
AUDIO
Y
P
b
R
L
P
r
VCR
STB
DVD
Video Cable
Audio Cable
(Optional)
(Optional)
R
L
VIDEO
AUDIO
AV
DVD
Video Cable
Audio Cable
STB
VCR
(Optional)
(Optional)
