Specifications

Rated Input Power

The notebook operates on DC power, which can be supplied by
an AC or a DC power source. Although the notebook can be
powered from a stand-alone DC power source,HP strongly
recommends that the notebook be powered only with an
AC adapter or DC cable supplied or approved by HP.

An AC adapter provided by HP for use with this notebook is
capable of accepting AC power within the following
specifications:

Operating voltage

18.5V DC @ 3.5A - 65W

Operating current

4.9A

This product is designed for IT power systems in Norway with
phase-to-phase voltage not exceeding 240 Vrms.

Input Power

Rating

Operating voltage

100–240V AC @ 1.7A - 50–60Hz

Operating current

1.5A rms

Operating frequency range

50 to 60Hz

The notebook is capable of accepting DC power within the
following specifications:

Input Power

Rating

A-2

Startup and Reference Guide––Part 2
